Intel NUC 12 Pro Kit i7 Wall Street Canyon NUC12WSHi7
Never available again
View alternatives in the sidebar
View alternatives in the sidebar
Built-in WiFi | ||
|---|---|---|
Nubmber of M.2 connectors | 6 | |
Number of HDMI connectors | 2 | |
Bluetooth | ||
Integrated video card |
According to our barebone expert
The Intel NUC 12 Pro Kit i7 Wall Street Canyon NUC12WSHi7 is a barebone mini computer that's suitable for your daily work and video editing. Think of writing reports in Microsoft Word or editing company videos in Adobe Premiere Pro. This barebone has a 12th generation Intel Core i7 processor and has space for 64GB DDR4 RAM with a maximum clock speed of 3200MHz. You have 3 M.2 PCIe 4.0 slots for the storage space. With this, you can combine a large storage capacity with fast boot times. You can connect the mini PC to up to 4 screens at the same time via the HDMI, DisplayPort, or USB-C / Thunderbolt connectors. In addition, you have enough space for the dongles of a wireless mouse and keyboard via the various USB-A ports. This barebone also supports both wired and wireless internet. Don't want the barebone on your desk? Mount it behind the monitor with the included VESA mount. In addition, this barebone supports Windows 11 Home and Pro, Windows 10 Home, Pro and Enterprise, Windows 10 IoT Enterprise, RedHat EL Linux, and Ubuntu 20.04 LTS.
5 stars
0
4 stars
0
3 stars
0
2 stars
0
1 star
0
Product number | 933051 | |
|---|---|---|
Manufacturer code | RNUC12WSHI70002 | |
Brand | Intel | |
Warranty | 2 years | |
Processing of your defect | Via Coolblue |
Compatible with Windows version | Windows 10, Windows 11 |
|---|
Processor brand | Intel | |
|---|---|---|
Processor cores | Dodeca-Core (12) | |
Threads | 16 |
Clock speed | 2,1 GHz | |
|---|---|---|
Overclockable | ||
Turbo speed | 4,7 GHz | |
Cache memory | 18 MB | |
Number of performance cores | 12 | |
Integrated graphics | ||
Type of integrated graphics | Intel Iris Xe Graphics |
Total number of RAM slots | 2 | |
|---|---|---|
Voltage RAM | 1.2V |
Integrated video card |
|---|
Nubmber of M.2 connectors | 6 | |
|---|---|---|
Supported M.2 SSD formats | 22x80mm | |
M.2 SSD connector type | B+M | |
Number of SATA connectors | 1 |
Bluetooth | ||
|---|---|---|
Bluetooth version | 5.3 | |
Built-in WiFi | ||
Ethernet port | ||
Number of Ethernet ports | 1 |
HDMI connector | ||
|---|---|---|
Number of Female HDMI type A 2.1 ports | 2 | |
DisplayPort connector | ||
Number of Female Standard DisplayPort 1.4a ports | 2 | |
Thunderbolt connector | ||
Number of Female Thunderbolt 4 (USB-C) ports | 2 |
USB-A ports front panel | ||
|---|---|---|
Total amount USB-A ports front panel | 2 | |
USB-C ports front panel |
USB-A ports back panel | ||
|---|---|---|
Total number of USB-A ports back panel | 2 | |
Number of USB-A 2.0 (480Mbps) ports back panel | 1 | |
USB-C ports back panel | ||
Total number of USB-C ports back panel | 2 | |
Number of USB-C 4.0 (40Gbps) ports back panel | 2 |
Headphone jack | ||
|---|---|---|
Number of female 3.5mm TRS Audio Jack ports | 1 | |
Microphone connector | ||
Number of microphone connectors | 1 | |
Type of microphone connection | 3.5mm jack |
Width | 11,7 cm | |
|---|---|---|
Height | 3,7 cm | |
Depth | 11,2 cm | |
Color | Black | |
Material | Plastic |
