Choose your network switch:
5
|
Yes
|
No
|
2
Number of ethernet ports
Managed switch
Number of switches
According to our network switch expert
This TP-Link TL-SG105E package has 2 switches with 5 network connectors each. You configure the switches via the software from TP-Link. This lets you prioritize important internet traffic, such as phone calls or streams. That way, these don't get interrupted when you're downloading a lot. You can divide your network into 32 virtual networks with these switches, so you can choose who gets access to certain parts of your network. You can easily mount these switches underneath a desk or on the wall.
5 stars
982
4 stars
490
3 stars
42
2 stars
6
1 star
6
Degelijkheid
Energieverbruik
Snelheid
Installatie- & gebruiksgemak
Mogelijkheden
I bought this switch because my T-mobile router only has 2 ethernet ports available (other 2/4 for TV for now) Looks solid and is nicely compact. Based on the website I thought I would get the "Easy Smart Switch", when the package arrived it turned out to be an "Unmanaged Pro" variant with the same model number (TL-SG105E) After some communication with Coolblue and the manufacturer, it turns out to be the same product. (other branding only) With me there was no CD (according to the description website CB) but you don't need that either. Any new(er) firmware can be found on the TP-Link website: https://www.tp-link.com/nl/support/download/tl-sg105e/ !Make sure you choose the correct hardware version! (it's on the sticker on the bottom of the switch) For me it was V4. (So don't automatically choose the last one!)
To configure the switch, you will have to make a direct (1on1) network connection with a PC/laptop. Default IP of the switch is then: 192.168.0.1 (default login: admin, admin) Put your PC (temporarily) in the same IP range, e.g. 192.168.0.2 (Network, change adapter options, Ethernet, Properties, Internet Protocol version 4 (TCP/IPv4), choose a manual IP)
if you place the switch directly in your network, it works like a switch, so you don't just get to the web interface. Network cables in and go.
rubber (adhesive) feet included (I have not used) I hung the switch on 1 of the 2 "Screw eyes" on the back.
All in all I am very satisfied with it.
F. Boersma
8 April 2020
Automatically translated from Dutch
Many options for an entry model switch. POE, Manageble and Vlan support. You don't find that much on switches in this price range. Comes in a sturdy housing.
Frank Pietersma
17 August 2018
Automatically translated from Dutch
The power-saving function puts a port in standby when it is not in use. Unfortunately it takes too long to get out of this standby mode. This ensures that a vpn connection times out after a while, to prevent you from disconnecting you have to reactivate the port by looking up something on the internet or something. Really super annoying, I regret my purchase so much because I will probably disconnect this switch and no longer use it. Tried a firmware update and first time switch was bricked (despite following tplink manual). Fortunately, I received a new device from coolblue, so their service is good.
Peter Lacres
20 March 2016
Automatically translated from Dutch
Product number | 536278 | |
|---|---|---|
Manufacturer code | TL-SG105E | |
Brand | TP-Link | |
Warranty | Lifetime | |
Processing of your defect | Via Coolblue |
Managed switch | ||
|---|---|---|
Smart managed | ||
Fully managed | ||
Number of Ethernet ports | 5 | |
Ethernet speed | Gigabit Ethernet (1000Mbps) | |
Switching capacity | 10 Gbit/s | |
SFP/GBIC ports | 0 | |
Quality of Service (QoS) | ||
LACP Link aggregation | ||
IGMP Snooping | ||
VLAN | ||
Maximum number of VLANs | 32 | |
Jumbo frame support | ||
Port mirroring | ||
Professional use | ||
Suitable for business use in | Home office |
PoE support | ||
|---|---|---|
Highest PoE stand | No PoE |
Fan present | ||
|---|---|---|
Mounting possible | ||
Suitable for 19-inch rack mount | ||
Weight | 290 g | |
Color | Black | |
Height | 2,5 cm | |
Width | 9,98 cm | |
Depth | 9,8 cm | |
Material | Metal | |
Guided collections test property | 1 switch | 1Gbps Ethernet speed | 0 SFP ports, 1Gbps Ethernet speed | Not suitable for 19-inch rack |
